Flat Slab–Column Modeling Using Finite Element with Eccentric Loading Effects

الباحث الأول: Haider A. A. Al‑Katib

الباحثين الآخرين: Hayder H. Alkhudery1 · Aseel A. A. Al‑Katib1

المجلة: Iranian Journal of Science and Technology, Transactions of Civil Engineering

تاريخ النشر: None

مختصر البحث:

Abstract Slab–Column connection is one of the critical structural joints in building construction, since there are special design requirements that must be achieved. This paper investigates RC slab–column connections under eccentric load using a … Abstract Slab–Column connection is one of the critical structural joints in building construction, since there are special design requirements that must be achieved. This paper investigates RC slab–column connections under eccentric load using a built-in 3-Dimensional Nonlinear program of fnite element in the pre- and post-cracking levels and up to the ultimate load. The concrete is simulated as isoparametric brick element, and the reinforcement bar elements are assumed to be built into isoparametric brick elements. With regard to load–defection responses and ultimate strength capacity, a good coincidence is achieved for FEA and experimental results with maximum diference 1.6% for ultimate strength. In addition, the structural performance investigation of slab–column connection is carried in terms of the efectiveness of applied load types, shear reinforcement and slab thickness. It can be concluded that the increase in loading eccentricity cause decreasing in ultimate load 20.5 to 40% in comparison with case of e=0, which is one of conclusion of this research. Also, the use of shear reinforcement (48 stirrups of Φ10 mm) in the fat slab connection with columns had more efects than slab depth. It is found that the ultimate load capacity increases about 34.4% with e=0.0, while it decreases about 22% with e=0.45 m when compared with slab–column connections without shear reinforcement (e=0.0). In addition, as the slab thickness increases from 150 to 200 mm, the ultimate load increases about (25%) when compared with case of (e=0.0), while the ultimate load increases about (2.3%) when compared with the same case of (e=0.0), which means that the increment in the slab thickness can be considered as compensation for the efects of increasing in load eccentricity. Also, for the slab–column connection without shear reinforcement, the related formula of ACI-code gives a good agreement in terms of ultimate load capacity in comparison with the results of adopted FE model with maximum diference 4% as the unbalanced moment was increased, while for usage of shear reinforcement in slab–column connection, the formula of ACI-code becomes more conservative with maximum diference 10% with increasing of unbalanced moment.

عرض المزيد عرض البحث

ARTIFICIAL NEURAL NETWORK MODEL FOR FLEXURAL DESIGN OF CONCRETE HYDRAULIC STRUCTURES

الباحث الأول: Oday M. Albuthbahak and Hayder H. Alkhudery Faculty of Engineering, University of Kufa, Najaf, Iraq

المجلة: International Journal of Civil Engineering and Technology (IJCIET)

تاريخ النشر: None

مختصر البحث:

As a computer technique, Artificial Neural Networks (ANNs) have expanded in use with engineering fields. ANNs have been used in many civil engineering problems and some of them were used in the design of concrete structural elements and have shown a…

عرض المزيد عرض البحث

INVESTIGATION OF EFFECTIVE HYBRID FRP AND STEEL REINFORCEMENT RATIO FOR CONCRETE MEMBERS

الباحث الأول: HAYDER H. ALKHUDERY, ODAY M. ALBUTHBAHAK, and HAIDER A. A. AL-KATIB Faculty of Engineering, University of Kufa, Najaf, Iraq

المجلة: Meswell journal

تاريخ النشر: None

مختصر البحث:

Fiber reinforced material (FPR) has become an effective alternative reinforcement for concrete constructions owing to their higher ultimate strength in tension and strongly anticorrosive properties. However, the low ductility behaviour of FRP reinfo…

عرض المزيد عرض البحث

BEHAVIOR OF POLYPROPYLENE FIBERS REINFORCED CONCRETE MODIFIED WITH HIGH PERFORMANCE CEMENT

الباحث الأول: Haider A. A. Al-Katib, Hayder H. Alkhudery, and Haider Ali Al-Tameemi

المجلة: www.iaeme.com/ijciet/issues.asp?JType=IJCIET&VType=9&IType=5

تاريخ النشر: None

مختصر البحث:

Fiber reinforced concrete is an improved type of concrete that containing fibers randomly distributed inside it. Usually, the mechanical properties of concrete have been developed namely, compressive, flexural, and tensile strength by adding the f…

عرض المزيد عرض البحث

Finite element Investigation of Design Formula for Thin Walled Plates Supported by Foam under Buckling Load

الباحث الأول: Hayder H. Alkhudery Faculty of Engineering, University of Kufa Haider A. A. Al-katib Faculty of Engineering, University of Kufa Aseel A. A. Al-Katib Faculty of Engineering, University of Kufa

المجلة: International Conference on Recent Innovation in Engineering , Science and Management (ICRIESM-2018)

تاريخ النشر: None

مختصر البحث:

The thin-walled plate and foam of low material is components of sandwich panels, one of the attractive engineering structures mixed between different two materials to accomplish high ultimate strength integrated with light weight structures. Usual…

عرض المزيد عرض البحث

Effect of Uplift Pressure under Hydraulic Structure Founded on Isotropic and Anisotropic Soil

الباحث الأول: Aseel A. A. Al-Katib Faculty of Engineering,University of Kufa Haider A. A. Al-Katib Faculty of Engineering,University of Kufa Hayder H. Alkhudery Faculty of Engineering,University of Kufa

المجلة: International Journal of Engineering Technology Science and Research IJETSR

تاريخ النشر: None

مختصر البحث:

In this research, “Slide” program was used to analyze seepage flow under the hydraulic structure through isotropic and anisotropic soils and its effect on structures with cut-off at downstream, at upstream, and at both of them. The distribution cu…

عرض المزيد عرض البحث

Flexural behavior of Glass Panels

الباحث الأول: 1Ashraf Amer, 2Oday Mohammed, 3Hayder Hussain 1Asharf A. M. R. Hiswa, Faculty of Engineering/University of Kufa, Najaf, Iraq

المجلة: International Journal of Engineering Technology Science and Research IJETSR

تاريخ النشر: None

مختصر البحث:

This paper presents a work to validate formulae for maximum stress and deflection in glass panels by physical testing. The formulae were generated from finite element modelling using ANSYS. The physical testing revealed that unless the glass panel …

عرض المزيد عرض البحث

حيدر حسين صالح الخضري

حيدر حسين صالح الخضري

الملف الشخصي

الاهتمامات البحثية

البحوث المنشورة

Flat Slab–Column Modeling Using Finite Element with Eccentric Loading Effects

ARTIFICIAL NEURAL NETWORK MODEL FOR FLEXURAL DESIGN OF CONCRETE HYDRAULIC STRUCTURES

INVESTIGATION OF EFFECTIVE HYBRID FRP AND STEEL REINFORCEMENT RATIO FOR CONCRETE MEMBERS

BEHAVIOR OF POLYPROPYLENE FIBERS REINFORCED CONCRETE MODIFIED WITH HIGH PERFORMANCE CEMENT

Finite element Investigation of Design Formula for Thin Walled Plates Supported by Foam under Buckling Load

Effect of Uplift Pressure under Hydraulic Structure Founded on Isotropic and Anisotropic Soil

Flexural behavior of Glass Panels
